The Jeep Timing Camshaft Sprocket S822 is a precision timing gear designed specifically for Jeep engines, ensuring perfect synchronization of valve and piston movement. Forged from aircraft-grade alloy steel, heat-treated and CNC-machined, it provides excellent wear resistance and fatigue resistance, extending engine life.
Precise Compatibility: Perfect match for Jeep 3.6L/3.8L Pentastar engines (2012-2023 models).
OEM Standard: Strictly follow original factory specifications, direct replacement without modification requirements.
Dynamic Balancing: Laser calibration reduces vibration and improves engine smoothness.
| Specification |
Detail |
| Product Model |
S822 |
| Applicable Engine |
Jeep 53010400 / 53010557AA |
| Number of Teeth |
48 Teeth (Dual-Row Design) |
| Applicable Models |
Jeep Cherokee / Grand Cherokee / TJ Wrangler |
| Material |
High-Precision Cast Alloy (SAE 8620 Carburized Steel) |
| Tooth Design |
ISO 606 Standard Tooth Profile | ±0.03mm Precision Grinding |
| Surface Treatment |
Case Hardened to HRC 60-65 | Anti-Corrosion Phosphate Coating |
Product Installation Instructions
Preparation before Installation
Make sure the engine is cool to avoid high temperature causing deformation of components.
Check the status of the Timing Chain to ensure there is no damage or excessive wear.
Installation Steps
Connect one end of the Timing Chain to the Crankshaft Sprocket and ensure that the Timing Mark is aligned.
Install the Camshaft Sprocket onto the Camshaft, making sure the Timing Mark is aligned with the Timing Mark of the Crankshaft Sprocket.
Use the special tool to fix the Camshaft Sprocket to ensure a secure installation.
Installation precautions
During the installation process, be careful not to get your fingers stuck between the Camshaft Sprocket and the Timing Chain to avoid injury.
After installation, check the tension of the Timing Chain to ensure it is within the normal range.
